WW1325A Wood Engraving Machine
Entry-level three axis made from fully stress-relived structured steel for cutting and carving flat board. The Routers features • Precision ball scree drives • Rack and pinion transmission • Multi-zone vacuum plenum • World renown HIWIN bearings • Windows® based easy-to-learn and use G-Code Interface (multiple languages).
|
Entry-level
WOOD ENGRAVING MACHINE
Models |
Traveling Area
(mm) |
Cut Speed
(mm/min) |
Frame |
G.W.
(kgs) |
Packing Size
(mm) | ||||
|
X |
Y |
Z |
L |
W |
H | ||||
|
WW1313 |
1300 |
1300 |
200 |
25000 |
Welded Steel |
1200 |
2200 |
1900 |
1900 |
|
WW1325 |
1300 |
2500 |
200 |
25000 |
Welded Steel |
1650 |
3200 |
2200 |
1900 |
|
WW1325H |
1300 |
2500 |
400 |
25000 |
Welded Steel |
1700 |
3200 |
2200 |
2200 |
|
WW1530 |
1500 |
3000 |
200 |
25000 |
Welded Steel |
1950 |
6800 |
2200 |
1900 |
|
WW2030 |
2000 |
3000 |
200 |
25000 |
Welded Steel |
2250 |
3800 |
2200 |
1900 |
|
WW2525 |
2500 |
2500 |
200 |
25000 |
Welded Steel |
2400 |
3300 |
3000 |
1900 |
|
WW2040 |
2000 |
4000 |
200 |
2500 |
Welded Steel |
2700 |
4800 |
2200 |
1900 |
|
WW2550 |
2500 |
5000 |
300 |
25000 |
Welded Steel |
3100 |
6100 |
3000 |
1900 |
|
Options |
Full range of tables sizes
4’(1300mm) X 4’(1300mm) to 10’(3000mm) X 20’(6000mm) | ||||||||
| Vacuum pumps for easy part fixturing | |||||||||
| Wide range of spindle options 2HP(1.5KW) to 10 HP(7KW) | |||||||||
| Digital AC servo for high-speed/acceleration cutting | |||||||||
| Coolant mist systems for non-ferrous metal cutting | |||||||||
| Rotary for carving cylinder | |||||||||
| Dust collector for collecting clastic during processing to product rails and spindle | |||||||||
| Ncstudio/Mach3/ Syntec/ Siemens control system, etc. | |||||||||
 |
 |
 |
 |
|
Italian HSD Air Cooling Spindle |
Domestic Air Cooling Spindle |
Domestic Water Cooling Spindle |
Italian Colombo Air Cooling Spindle |
|
|
|
|
|
|
|
|
Chinese CS ATC Air Cooling Spindle |
Italian HSD ATC Air Cooling Spindle |
Chinese ATC Water Cooling Spindle |
Italian HSD 5axis ATC Water Cooling Spindle |
Italian HSD ATC Water Cooling Spindle |
Italian Hiteco ATC Air Cooling Spindle |
|
|
|
|
|
|
Fuxing Stepper Motor |
Taiwan Delta Servo Motor |
Japanese Panasonic Servo Motor |
Japanese Yaskawa Servo Motor |
|
|
|
|
|
|
Japanese Fanuc Servo Motor |
France Siemens Servo Motor |
Taiwan Apex Reducer |
Japanese Shimpo Reducer |
|
|
|
|
|
|
Rich Auto DSP Controller |
Ncstudio DSP Controller |
Ncstudio Software Controller |
Mach3 Software Controller |
|
|
|
|
|
|
France Siemens Controller |
Taiwan Syntec Controller |
Japanese Fanuc Controller |
Italian Osai Controller |
 |
 |
 |
|
Fuling Inverter |
Taiwan Delta Inverter |
Japanese Omron Inverter |
 |
 |
 |
 |
 |
|
France Schneider Contactor |
France Schneider Main Switch |
Japanese Omron 24V Power Supply |
Japanese Omron Limit Sensor |
Japanese Omron Power Switch |
 |
 |
 |
 |
 |
|
Taiwan HIWIN Square Rails |
Taiwan TBI Ball Screw |
High Precision Helical Rack Gear 1.25mol |
LanPu Transformer |
High Quality Auto Lubrication System |
 |
 |
 |
 |
 |
|
Good Quality High-rise Flexible Wire |
Hard Rubber Limited |
Protect Fuses |
Vacuum &T-slot Combined Table |
High-quality Belt |
 |
 |
 |
 |
 |
|
Rotary-Removable Type |
Rotary-At the End of Machine |
Rotary-On the Side of Machine |
Germany SCHMLAZ Vacuum Beam |
Stainless Steel Water Slot |
 |
 |
 |
 |
 |
|
Linear Tool Magazine |
Carrousel Tool Magazine |
Tool Sensor System |
Water Chiller |
Air Compressor |
 |
 |
 |
 |
 |
|
Germany Becker Vacuum Pump |
Chinese Water Cooling Pump |
TY Air Cooling Pump |
Snail Air Cooling Vacuum Pump |
Italian HSD Boring Unit |
 |
 |
 |
 |
|
|
Mist Cooling System |
Dust Collector |
Hand Wheel |
Material Alignment System |
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.
|
