ATC1325C ATC CNC Router
Overview
Woodworking entry-level ATC CNC Router standard features include a 12 HP HSD high frequency automatic tool changer spindle with an 8 Position tool holder rack(in linear type or rotary carousel type, multi-zone vacuum t-slot table combination, and material placement stops and are manufactured using global state-of-the-art techniques with all steel construction.
Applications
3D Carving, Acrylic Fabrication, Aluminum Fabrication, Architectural Millwork, Cabinetry, Exhibits and Fixtures, Signmaking, Arts and Crafts, Furniture, Musical Instruments and More.
Material Cut
Acrylic, ACM, Copper, Brass, Aluminum, PVC, MDF, Melamine plastic, Foam, Melamine, Phenoic, Plywood, HDPE, Solid Surface, Solid Wood, etc.
Features
|
ATC Router
Models |
Traveling Area
(mm) |
Cut Speed
(mm/min) |
Frame |
G.W.
(kgs) |
Packing Size
(mm) | ||||
|
X |
Y |
Z |
L |
W |
H | ||||
|
ATC1325L |
1300 |
2500 |
300 |
25000 |
Welded Steel |
2100 |
3750 |
2250 |
2100 |
|
ATC1325C |
1300 |
2500 |
300 |
25000 |
Welded Steel |
2450 |
3750 |
2250 |
2100 |
|
Options |
Full range of tables sizes
4’(1300mm) X 6’(2500mm) to 10’(3000mm) X 20’(6000mm) | ||||||||
|
Vacuum pumps for easy part fixturing | |||||||||
|
Wide range of spindle options 12HP(9KW) to 19 HP(14KW) | |||||||||
|
Fam Drill Bank(5 + 4 Vertical/ 9 VERTICAL + 2 HORIZONTAL SPINDLES
+ 2 BLADE UNITS or other configurations are available upon request. | |||||||||
|
Auto positioning rods | |||||||||
|
Another machine head for normal work | |||||||||
|
Coolant mist systems for non-ferrous metal cutting | |||||||||
|
Rotary for carving cylinder | |||||||||
|
Dust collector for collecting clastic during processing to product rails and spindle | |||||||||
|
Syntec/ Siemens control system, etc. | |||||||||
Video
Machine Schematic
1. Spindle
1.1 Manual Change Spindle
 |
 |
 |
 |
|
Italian HSD Air Cooling Spindle |
Domestic Air Cooling Spindle |
Domestic Water Cooling Spindle |
Italian Colombo Air Cooling Spindle |
1.2. ATC Spindle
|
|
|
|
|
|
|
|
Chinese CS ATC Air Cooling Spindle |
Italian HSD ATC Air Cooling Spindle |
Chinese ATC Water Cooling Spindle |
Italian HSD 5axis ATC Water Cooling Spindle |
Italian HSD ATC Water Cooling Spindle |
Italian Hiteco ATC Air Cooling Spindle |
2. Motor
|
|
|
|
|
|
Fuxing Stepper Motor |
Taiwan Delta Servo Motor |
Japanese Panasonic Servo Motor |
Japanese Yaskawa Servo Motor |
|
|
|
|
|
|
Japanese Fanuc Servo Motor |
France Siemens Servo Motor |
Taiwan Apex Reducer |
Japanese Shimpo Reducer |
3. Control System
|
|
|
|
|
|
Rich Auto DSP Controller |
Ncstudio DSP Controller |
Ncstudio Software Controller |
Mach3 Software Controller |
|
|
|
|
|
|
France Siemens Controller |
Taiwan Syntec Controller |
Japanese Fanuc Controller |
Italian Osai Controller |
4. Inverter
 |
 |
 |
|
Fuling Inverter |
Taiwan Delta Inverter |
Japanese Omron Inverter |
Basic Accessories
 |
 |
 |
 |
 |
|
France Schneider Contactor |
France Schneider Main Switch |
Japanese Omron 24V Power Supply |
Japanese Omron Limit Sensor |
Japanese Omron Power Switch |
 |
 |
 |
 |
 |
|
Taiwan HIWIN Square Rails |
Taiwan TBI Ball Screw |
High Precision Helical Rack Gear 1.25mol |
LanPu Transformer |
High Quality Auto Lubrication System |
 |
 |
 |
 |
 |
|
Good Quality High-rise Flexible Wire |
Hard Rubber Limited |
Protect Fuses |
Vacuum &T-slot Combined Table |
High-quality Belt |
Options
 |
 |
 |
 |
 |
|
Rotary-Removable Type |
Rotary-At the End of Machine |
Rotary-On the Side of Machine |
Germany SCHMLAZ Vacuum Beam |
Stainless Steel Water Slot |
 |
 |
 |
 |
 |
|
Linear Tool Magazine |
Carrousel Tool Magazine |
Tool Sensor System |
Water Chiller |
Air Compressor |
 |
 |
 |
 |
 |
|
Germany Becker Vacuum Pump |
Chinese Water Cooling Pump |
TY Air Cooling Pump |
Snail Air Cooling Vacuum Pump |
Italian HSD Boring Unit |
 |
 |
 |
 |
|
|
Mist Cooling System |
Dust Collector |
Hand Wheel |
Material Alignment System |
