Cabinet Processing Series CNC Machining Center
Overview
Single Arm CNC Machining Center standard features include a Italian 12 HP HSD high frequency automatic tool changer spindle with a carousel type rack(in linear type or rotary carousel type, Germany Schmalz moving vacuum table, and material placement stops and are manufactured using global state-of-the-art techniques with all steel construction.
Applications
Panel furniture industry: wood furniture, solid wood doors, decorative materials, cabinet doors, computer tables, mahjong table, office furniture, wooden sound box, wooden furniture, kitchenware and other processing.
Materials Cut
Features
|
Machining
Center
Models |
Traveling Area
(mm) |
Cut Speed
(mm/min) |
Frame |
G.W.
(kgs) |
Packing Size
(mm) | ||||
|
X |
Y |
Z |
L |
W |
H | ||||
|
SA1230 |
1200 |
3000 |
350 |
35000 |
Welded Steel |
3100 |
4550 |
2100 |
2100 |
|
SA1435 |
1400 |
3500 |
350 |
35000 |
Welded Steel |
3450 |
3800 |
2250 |
2300 |
|
Options |
Full range of tables sizes
4’(1300mm) X 6’(2500mm) to 10’(3000mm) X 20’(6000mm) | ||||||||
|
Vacuum pumps for easy part fixturing | |||||||||
|
Wide range of spindle options 12HP(9KW) to 19 HP(14KW) | |||||||||
|
Fam Drill Bank(5 + 4 Vertical/ 9 VERTICAL + 2 HORIZONTAL SPINDLES
+ 2 BLADE UNITS or other configurations are available upon request. | |||||||||
|
Material Alignment System Pusher Bar & Pop-up Side Rails | |||||||||
|
Suction Cup Load system | |||||||||
|
Coolant mist systems for non-ferrous metal cutting | |||||||||
|
Conveyor Table | |||||||||
Machine Schematic
1. Spindle
1.1 Manual Change Spindle
 |
 |
 |
 |
|
Italian HSD Air Cooling Spindle |
Domestic Air Cooling Spindle |
Domestic Water Cooling Spindle |
Italian Colombo Air Cooling Spindle |
1.2. ATC Spindle
|
|
|
|
|
|
|
|
Chinese CS ATC Air Cooling Spindle |
Italian HSD ATC Air Cooling Spindle |
Chinese ATC Water Cooling Spindle |
Italian HSD 5axis ATC Water Cooling Spindle |
Italian HSD ATC Water Cooling Spindle |
Italian Hiteco ATC Air Cooling Spindle |
2. Motor
|
|
|
|
|
|
Fuxing Stepper Motor |
Taiwan Delta Servo Motor |
Japanese Panasonic Servo Motor |
Japanese Yaskawa Servo Motor |
|
|
|
|
|
|
Japanese Fanuc Servo Motor |
France Siemens Servo Motor |
Taiwan Apex Reducer |
Japanese Shimpo Reducer |
3. Control System
|
|
|
|
|
|
Rich Auto DSP Controller |
Ncstudio DSP Controller |
Ncstudio Software Controller |
Mach3 Software Controller |
|
|
|
|
|
|
France Siemens Controller |
Taiwan Syntec Controller |
Japanese Fanuc Controller |
Italian Osai Controller |
4. Inverter
 |
 |
 |
|
Fuling Inverter |
Taiwan Delta Inverter |
Japanese Omron Inverter |
Basic Accessories
 |
 |
 |
 |
 |
|
France Schneider Contactor |
France Schneider Main Switch |
Japanese Omron 24V Power Supply |
Japanese Omron Limit Sensor |
Japanese Omron Power Switch |
 |
 |
 |
 |
 |
|
Taiwan HIWIN Square Rails |
Taiwan TBI Ball Screw |
High Precision Helical Rack Gear 1.25mol |
LanPu Transformer |
High Quality Auto Lubrication System |
 |
 |
 |
 |
 |
|
Good Quality High-rise Flexible Wire |
Hard Rubber Limited |
Protect Fuses |
Vacuum &T-slot Combined Table |
High-quality Belt |
Options
 |
 |
 |
 |
 |
|
Rotary-Removable Type |
Rotary-At the End of Machine |
Rotary-On the Side of Machine |
Germany SCHMLAZ Vacuum Beam |
Stainless Steel Water Slot |
 |
 |
 |
 |
 |
|
Linear Tool Magazine |
Carrousel Tool Magazine |
Tool Sensor System |
Water Chiller |
Air Compressor |
 |
 |
 |
 |
 |
|
Germany Becker Vacuum Pump |
Chinese Water Cooling Pump |
TY Air Cooling Pump |
Snail Air Cooling Vacuum Pump |
Italian HSD Boring Unit |
 |
 |
 |
 |
|
|
Mist Cooling System |
Dust Collector |
Hand Wheel |
Material Alignment System |
|
