4AXIS1325-ATC 4 Axis CNC Router
Overview
4 Axis ATC CNC Routers standard features include a 12 HP HSD high frequency automatic tool changer spindle with an 8 Position rotary carousel tool holder, the spindle(B axis) can rotate +/- 90 degree, for side slot milling, drilling, cutting, keyhole, very suitable for processing of on different surface carving.
Applications
Woodworking industry: wooden doors, cabinets, plate, office wood furniture, speakers, musical instruments, etc.
Plate processing: insulation, plastic and chemical, PCB, ABS, PP, PE and other carbon mixture.
Decoration industry: Acrylic, PVC, MDF, plastic and copper and aluminum and other soft metal plate engraving and milling.
Materials Cut
Acrylic, ACM, Copper, Brass, Aluminum, PVC, MDF, Melamine plastic, Foam, Melamine, Phenoic, Plywood, HDPE, Solid Surface, Solid Wood, etc.
Features
|
4 Axis ATC Router
Models |
Traveling Area
(mm) |
Cut Speed
(mm/min) |
Frame |
G.W.
(kgs) |
Packing Size
(mm) | ||||
|
X |
Y |
Z |
L |
W |
H | ||||
|
4AXIS1325-ATC |
1300 |
2500 |
400 |
30000 |
Welded Steel |
2500 |
3750 |
2250 |
2100 |
|
4AXIS1530-ATC |
1500 |
3000 |
400 |
30000 |
Welded Steel |
3150 |
3750 |
2250 |
2100 |
|
Options |
Full range of tables sizes
4’(1300mm) X 6’(2500mm) to 10’(3000mm) X 20’(6000mm) | ||||||||
|
Vacuum pumps for easy part fixturing | |||||||||
|
Wide range of spindle options 12HP(9KW) to 19 HP(14KW) | |||||||||
|
Auto positioning rods | |||||||||
|
Coolant mist systems for non-ferrous metal cutting | |||||||||
|
Rotary for carving cylinder | |||||||||
|
Dust collector for collecting clastic during processing to product rails and spindle | |||||||||
|
Syntec/ Siemens control system, etc. | |||||||||
Video
Machine Schematic
1. Spindle
1.1 Manual Change Spindle
 |
 |
 |
 |
|
Italian HSD Air Cooling Spindle |
Domestic Air Cooling Spindle |
Domestic Water Cooling Spindle |
Italian Colombo Air Cooling Spindle |
1.2. ATC Spindle
|
|
|
|
|
|
|
|
Chinese CS ATC Air Cooling Spindle |
Italian HSD ATC Air Cooling Spindle |
Chinese ATC Water Cooling Spindle |
Italian HSD 5axis ATC Water Cooling Spindle |
Italian HSD ATC Water Cooling Spindle |
Italian Hiteco ATC Air Cooling Spindle |
2. Motor
|
|
|
|
|
|
Fuxing Stepper Motor |
Taiwan Delta Servo Motor |
Japanese Panasonic Servo Motor |
Japanese Yaskawa Servo Motor |
|
|
|
|
|
|
Japanese Fanuc Servo Motor |
France Siemens Servo Motor |
Taiwan Apex Reducer |
Japanese Shimpo Reducer |
3. Control System
|
|
|
|
|
|
Rich Auto DSP Controller |
Ncstudio DSP Controller |
Ncstudio Software Controller |
Mach3 Software Controller |
|
|
|
|
|
|
France Siemens Controller |
Taiwan Syntec Controller |
Japanese Fanuc Controller |
Italian Osai Controller |
4. Inverter
 |
 |
 |
|
Fuling Inverter |
Taiwan Delta Inverter |
Japanese Omron Inverter |
Basic Accessories
 |
 |
 |
 |
 |
|
France Schneider Contactor |
France Schneider Main Switch |
Japanese Omron 24V Power Supply |
Japanese Omron Limit Sensor |
Japanese Omron Power Switch |
 |
 |
 |
 |
 |
|
Taiwan HIWIN Square Rails |
Taiwan TBI Ball Screw |
High Precision Helical Rack Gear 1.25mol |
LanPu Transformer |
High Quality Auto Lubrication System |
 |
 |
 |
 |
 |
|
Good Quality High-rise Flexible Wire |
Hard Rubber Limited |
Protect Fuses |
Vacuum &T-slot Combined Table |
High-quality Belt |
Options
 |
 |
 |
 |
 |
|
Rotary-Removable Type |
Rotary-At the End of Machine |
Rotary-On the Side of Machine |
Germany SCHMLAZ Vacuum Beam |
Stainless Steel Water Slot |
 |
 |
 |
 |
 |
|
Linear Tool Magazine |
Carrousel Tool Magazine |
Tool Sensor System |
Water Chiller |
Air Compressor |
 |
 |
 |
 |
 |
|
Germany Becker Vacuum Pump |
Chinese Water Cooling Pump |
TY Air Cooling Pump |
Snail Air Cooling Vacuum Pump |
Italian HSD Boring Unit |
 |
 |
 |
 |
|
|
Mist Cooling System |
Dust Collector |
Hand Wheel |
Material Alignment System |
Guarantee & After Sales Service
1. The machine is guaranteed for 12 months.
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.
2. Technical support by phone, e-mail or MSN around the clock.
3. Friendly English version manual and operation video CD disk.
