WWF1325 5 Axis CNC Router

Home>> 5Axis-CNC-Router>>5Axis CNC Router >> WWF1325 5 Axis CNC Router

WWF1325 5 Axis CNC Router

Overview

Designed for high-speed, heavy-duty routing, 5 Axis CNC Router are easy to configure to meet demanding application requirements in woodworking, plastics, non-ferrous metals and composites industries.

Applications

Mold industry: Various large metalloid moulds, especially suitable for automotive foam mold, wooden ship model, wooden model aviation, rail wooden mold and wooden mold train.

Instrument industry: 3D surface engraving and shape cutting of large-scale instruments.

Materials Cut

Acrylic, ACM, Copper, Brass, Aluminum, PVC, MDF, Melamine plastic, Foam, Melamine, Phenoic, Plywood, HDPE, Solid Surface, Solid Wood, etc.

Video

Features

Number	Description	Parameter
1	X Y Z C A Axis Working Area	13002500900mm* 210degree*180degree
2	Table Size	1550*2840mm
3	Positioning Accuracy	±0.02/300mm
4	Reposition Positioning Accuracy	±0.02/300mm
5	Table	Moveable Milling Steel (with T-slot)
6	Frame	Cast Iron (heavy stell)
7	Drive System X Axis	Rack and pinion
8	Drive System Z, Y Axis	Ball screw
9	Max. Power Consumption	14.2KW
10	Max. Velocity	25000mm/min
11	Max. Working Speed	15000mm/min
12	Spindle Speed	0-24000rmp
13	Work Mode	Yaskawa Servo Motor
14	Working Voltage	AC380V (220V)
15	Command Language	G Code
16	Interface	CF card, ethernet
17	Operating System	Osai
18	Flash Memory	512M
19	X-Y Resolution	0.02/300mm
20	Software	UGS, Alpha Cam,Becam,Type3, UcancamV9
21	Running Temperature	0 -45 centigrade
22	Packing Size	330022002000mm (in parts)
23	Net Weight	6550KGS
24	Gross Weight	7400KGS

Machine Schematic

1. Spindle

1.1 Manual Change Spindle


Italian HSD Air Cooling Spindle	Domestic Air Cooling Spindle	Domestic Water Cooling Spindle	Italian Colombo Air Cooling Spindle

1.2. ATC Spindle


Chinese CS ATC Air Cooling Spindle	Italian HSD ATC Air Cooling Spindle	Chinese ATC Water Cooling Spindle	Italian HSD 5axis ATC Water Cooling Spindle	Italian HSD ATC Water Cooling Spindle	Italian Hiteco ATC Air Cooling Spindle

2. Motor


Fuxing Stepper Motor	Taiwan Delta Servo Motor	Japanese Panasonic Servo Motor	Japanese Yaskawa Servo Motor

Japanese Fanuc Servo Motor	France Siemens Servo Motor	Taiwan Apex Reducer	Japanese Shimpo Reducer

3. Control System


Rich Auto DSP Controller	Ncstudio DSP Controller	Ncstudio Software Controller	Mach3 Software Controller

France Siemens Controller	Taiwan Syntec Controller	Japanese Fanuc Controller	Italian Osai Controller

4. Inverter


Fuling Inverter	Taiwan Delta Inverter	Japanese Omron Inverter

Basic Accessories


France Schneider Contactor	France Schneider Main Switch	Japanese Omron 24V Power Supply	Japanese Omron Limit Sensor	Japanese Omron Power Switch

Taiwan HIWIN Square Rails	Taiwan TBI Ball Screw	High Precision Helical Rack Gear 1.25mol	LanPu Transformer	High Quality Auto Lubrication System

Good Quality High-rise Flexible Wire	Hard Rubber Limited	Protect Fuses	Vacuum &T-slot Combined Table	High-quality Belt

Options


Rotary-Removable Type	Rotary-At the End of Machine	Rotary-On the Side of Machine	Germany SCHMLAZ Vacuum Beam	Stainless Steel Water Slot

Linear Tool Magazine	Carrousel Tool Magazine	Tool Sensor System	Water Chiller	Air Compressor

Germany Becker Vacuum Pump	Chinese Water Cooling Pump	TY Air Cooling Pump	Snail Air Cooling Vacuum Pump	Italian HSD Boring Unit

Mist Cooling System	Dust Collector	Hand Wheel	Material Alignment System
